England’s Stove Work Blue Ridge 500 Wood Stove ESW0012
Product Description
- High efficiency 3.5 ft³ firebox
- Up to 10 hours burn time
- 5/16″ steel top reinforced with a heat shield
- Cast iron door and ceramic glass
- EPA certified
- Proudly made in USA
- Non-catalytic combustion system
- Certified for mobile home and alcove installation
- Qualifies for the 30% US tax credit
- Included: pedestal, ash drawer & lip, air intake damper & rear air deflector
Appliance performance
|
Fuel type |
Dry cordwood (16″ recommended)
|
|
Recommended heating area |
1,000 – 2,700 ft² |
|
Overall firebox volume |
3.5 ft³ |
|
EPA loading volume |
2.88 ft³ |
|
Maximum burn time |
10 h |
|
Maximum heat output-dry cordwood |
110,000 BTU/h |
|
Minimum overall heat output rate |
17,200 BTU/h (5.0 kW) |
|
Maximum overall heat output rate |
57,800 BTU/h (16.9 kW) |
|
Average overall efficiency-dry cordwood (HHV |
71 % |
|
Average overall efficiency-dry cordwood (LHV |
76 % |
|
Optimum efficiency |
77 % |
|
Optimum heat transfer efficiency |
75 % |
|
Average particulate emission rate |
1.6 g/h |
|
Average CO |
73 g/h |
General Features
|
Alcove installation approved |
Yes |
|
Mobile home approved |
Yes, with fresh air intake |
|
Certified according to applicable standards |
CAN/USA accredited laboratory |
|
Overall dimension (Width) |
28 1/8″ |
|
Overall dimension (Height) |
35 1/8″ |
|
Overall dimension (Depth) |
31 1/4″ |
|
Premium quality blower included (CFM) |
Optional |
|
Combustion technology |
Non-catalytic |
|
Stainless-steel secondary-air system |
Yes |
|
Flue outlet diameter |
6″ |
|
Distance-center of the flue outlet to back unit |
8″ |
|
Distance-center of the flue outlet to side unit |
14 1/8″ |
|
Recommended chimney diameter |
6″ |
|
Type of chimney |
ULC-S629, UL 103 HT (2100 °F) |
|
Minimum chimney height |
12′ |
|
Door type |
Single, glass with cast iron frame |
|
Door opening size (Width) |
19″ |
|
Door opening size (Height) |
9 7/8″ |
|
Glass type |
Ceramic glass |
|
Glass surface – W x H |
16 5/8″ x 11 3/4″ |
|
Steel thickness-body |
3/16″ |
|
Steel thickness-top |
5/16″ |
|
Firebox size (Width) |
22 7/8″ |
|
Firebox size (Height) |
13″ |
|
Firebox size (Depth) |
20 1/8″ |
|
Log positioning |
Loading over width and over depth |
|
Maximum log length |
22″ oriented East-West |
|
Firebox lined with refractory bricks |
Yes |
|
Baffle type |
High quality vermiculite |
|
High-efficiency certified appliance |
Yes, EPA 2020 approved |
|
Canadian Standard (emissions) |
CSA B415.1-10 |
|
USA Standard (emissions) |
EPA |
|
Canadian Standard (safety) |
ULC S627 |
|
USA Standard (safety) |
UL 1482, UL 737 |
|
Warranty |
Limited 5 years |
|
Shipping weight |
480 lb (218 kg) |
Clearances
|
CLEARANCE |
SINGLE WALL PIPE | DOUBLE WALL PIPE |
|
Back wall |
13 3/4″ | 8″ |
|
Corner |
12″ | 12″ |
|
Side wall |
22″ | 19″ |
|
Base of the unit to ceiling |
84″ | 84″ |
Product Documents
Wood insert manual | Safety notifications & general information
